The EPD-500N Twin-Tower Nitrogen Generator is a robust and efficient system designed to deliver high-purity nitrogen up to 99% at a flow rate of 500 Nm³/Hr. Utilizing advanced Pressure Swing Adsorption (PSA) technology, it ensures consistent and reliable performance for a wide range of industrial applications. Equipped with an intelligent PLC control system and premium carbon molecular sieve, this generator offers exceptional energy efficiency, low operating costs, and long-term durability.
High Purity & Large Flow Output
Nitrogen Purity: Up to 99%
Flow Rate: 500 Nm³/Hr
Dew Point: ≤ -40°C
Output Pressure: 0.1–0.7 MPa
Intelligent Energy-Saving Control
VP (Variable Period) Control Logic adjusts cycle time based on real-time load:
80% load → 70s cycle → 20% less air consumption
50% load → 100s cycle → 50% less air consumption
30% load → 130s cycle → Over 60% energy saving
PLC + 7-inch Touch Screen for easy operation and remote monitoring via Modbus/RS485.
Advanced Molecular Sieve Filling Process
Combines Blizzard + Vacuum Loading + Vibration Platform for dense and stable packing.
Increases molecular sieve loading volume by ≥15% and prevents powdering during transit.
Ensures stable performance for up to 5 years without replenishment.
Durable & High-Performance Components
All Stainless Steel Pneumatic Valves (12 pcs/unit) with Y-type design, rated for 3 million+ cycles (approx. 6+ years).
Digital Flowmeter, Pressure Sensor, and Purity Analyzer for accurate real-time monitoring.
Long-Life Electrochemical Sensor (over 3 years) for reliable purity detection.
Automatic Purity Assurance
Standard Impure Nitrogen Auto-Exhaust System ensures only qualified nitrogen is delivered.
Fully automatic operation with no manual intervention required.
| Parameter | Value |
|---|---|
| Nitrogen Flow | 500 Nm³/Hr |
| Nitrogen Purity | 99% |
| Nitrogen Pressure | 0.1–0.7 MPa |
| Air Consumption | 18.3 m³/Min |
| Inlet Pressure | 0.6–0.8 MPa |
| Power Supply | 1Phase / 220V / 50Hz |
| Rated Power | 0.2 kW |
| Dimensions (L×W×H) | 2700×1600×2480 mm |
| Weight | 3780±100 kg |
Food & Beverage Packaging
Electronics & Semiconductor Manufacturing
Pharmaceutical & Chemical Processes
Laser Cutting & Metal Heat Treatment
Oil & Gas Inerting & Blanketing
High Efficiency & Low Air-Nitrogen Ratio – Reduces compressed air usage and operational costs.
Unequal Pressure Equalization – Enhances adsorbent utilization and gas purity stability.
Remote Control & Monitoring – Supports Modbus/RS485 for seamless integration.
Long Service Life – Molecular sieve lasts up to 5 years under normal conditions.
Customizable Options – Available for specific purity, flow, or configuration needs.
